Project File: Bund Lining
The Task
This project involved the re-lining of Diesel Tank Bunds with a Sprayglass SJ system, including the removal of loose or damaged existing bitumen.
Why LCM?
LCM specialises in the critical task of lining concrete bunds and tanks. Our highly skilled team of applicators, all certified in safety and confined space procedures, ensures that our projects are executed with precision and adherence to the highest industry standards.
With a proven track record of successful project completion in even the most challenging environments, LCM is a trusted partner for organisations seeking reliable and safe coating solutions.
LCM offers a wide range of coatings, from GRP laminates to epoxy, tailored to meet specific environmental and performance needs. Our experts carefully select the ideal solution for each project, ensuring both protection and compliance.
The Sprayglass SJ System is a robust lining solution engineered to protect concrete and steel substrates from corrosion and chemical degradation.
This heavy-duty system, composed of polyester or vinyl ester resins reinforced with chopped strand glass fibre mat, is applied in a multi-layer process to a nominal thickness of 2.5 to 3 mm. The system includes:
- SJ Primer: A specially formulated primer designed for optimal adhesion to the substrate.
- Silica-Filled Base Coat: A resilient base layer approximately 1.5 mm thick.
- Glass Fibre Mat: A layer of 600 gsm chopped strand glass fibre mat impregnated with resin for added strength and durability.
- Surfacing Tissue and Resin: A reinforcing layer to ensure a smooth and even finish.
- Waxed Resin Rich Top Coat: A protective topcoat that provides a barrier against environmental factors and chemicals.
